The UN series is designed with no compromise, to perform as well as many of the premium high SPL loudspeakers available. Full bodied sound with strong vocals coming through clear with extreme SPL efficiency was the goal, and the Ultra Neos surpassed all expectations.
UN-12 12” Specifications:
Lightweight French OEM Treated Paper cone, mated to a Kapton former and custom 2 7/16" edgewound coil.
Extremely strong N38H Grade Full-Circumference Neodymium Motor with 1 piece CNC T-Yoke and Top plate.
Stitched tinsel leads on linear Nomex spider.
CNC Vented Cast Aluminum Frame
Rated at 500w RMS
dBSPL 1w/1m: 96dB
Fs: 62hz
Mounting Dimensions:
Overall Diameter: 12 1/2"
Hole Cutout: 11 1/8"
Mounting Depth: 4 3/4"
Flush mount Depth: .55"
Recommended power range per speaker: 100rms-500rms
Usable Frequency response: 60-4500hz
Sold individually and available in 4ohm or 8ohm.
