DS18 PRO-D2PH 2" Throat Bolt On Compression Driver 3" Phenolic VC 800 Watts 8 ohm

  • $129.95
    Unit price per

Shipping calculated at checkout.

SHIPPING & DELIVERY INFORMATION

DESCRIPTION

Drivers are known for their extreme loudness all while maintaining the highest efficiency and decibel to wattage ratio possible. Ferrite is definitely a great motor structure you want to go with for the absolute loudest ear piercing high range frequencies available. This ferrite driver is compatible with 4 bolt horns (throats) of all sizes and depths. This will be an amazing addition to any system that needs super loud highs with no compromises!

This driver comes with a large phenolic 2 inch voice coil that takes 200 AES and 800 Peak power for extreme decibel production backed with a high efficiency motor.

Highlights

  • Ferrite motor structure that provides great motor force and loudness.
  • High strength phenolic voice coil taking 200 AES watts and 800 Peak watts.
  • Intense high frequency volume without sacrificing sound quality.
  • Compatible with all DS18 4 bolt throats giving a huge variety of mounting depths for your specific application.



Throat Diameter 2" / 50.8mm
Installation Type Bolt-On
Nominal Impedance 8 Ohms
AES Power Handling 200W
Program Power Handling 400W
Peak Power Handling 800W
Sensitivity 109 dB
Frequency Response 500Hz - 10KHz
Recommended Hi Pass Crossover 800 Hz
MOTOR
Voice Coil Diameter 3" / 76.2mm
Voice Coil Former Material Kapton
Winding Material Aluminum
Diaphragm Material Phenolic
Magnet Material Ferrite
Magnet Weight 65 oz
Body Material Aluminum
Body Color / Finish Black Aluminum / Machined
MEASUREMENTS
Overall Diameter 6.69" / 170mm
Overall Depth 3.2" / 81.4mm
Bolt Pattern Type 4*M6
