DS18 PRO-EXL 12" Mid-Bass Loudspeaker 1200 Watts 4-Ohm

Product type:

Vendor: DS18

Availability:

$199.95

Add to the wishlist

The people who live and breathe car audio demanded a higher-performing, extremely effective, and dynamic product series. After several months, and money allocated to R&D, DS18 is proud to launch the PRO-EXL Extremely Loud midrange series. They are the epitome of competition-quality midranges. Red aluminum baskets, cloth-edges, non-pressed paper cone, and the option for 8 ohm or 4 ohm impedance; these are only the basic components, the rest is pure DS18 technology.

Download Manual


Specifications
Model: PRO-EXL124MB
Type: Midbass Loudspeaker
Size: 12"
RMS Power: 700W
MAX Power: 1400W
Frequency Response: 62-6.3KHz
Impedance: 4 ohm
Sensitivity: 96dB
Materials
Surround: Cloth Edge
Frame: Red Aluminum Basket
Cone: Non-Pressed Paper Cone
Magnet: Ferrite
Voice Coil Wire: KCCAW
Diameters
Voice Coil Size: 3"
Magnet Size: 110 oz
Mounting Depth: 5.20"
Cut-Out Dimension: 11.22"
