Taramps MD12000.1 12000 Watt Class D Amplifier
$789.99 $879.99 10% Off
  • SKU :
  • Brand : Taramps

people are currently viewing this product

Description

The MD 12000.1 1 OHM amplifier module, is carefully designed with the highest technology, and high performance for automotive sound systems. It is a mono amplifier and its maximum power is 12000W RMS with 1 OHM impedance, and one 12000w RMS channel. The MD 12000 is FULL RANGE this way you appreciate all the frequencies in the right measure.

Operation class Class D
Number of Channels 01
Maximum power @ 12,6 VDC - 1 OHM: 12000W RMS
@ 12,6 VDC - 2 OHMS: 7200W RMS
Input Sensitivity 220mV
Signal to Noise Ratio >95dB
Frequency response 10Hz ~ 5KHz(-3dB)
Crossover high pass (HPF) 10Hz ~ 90Hz (-12dB/8ª) Variable
Crossover low pass (LPF) 90Hz ~ 5KHz (-12dB/8ª) Variable
Bass Boost 35Hz ~ 55Hz
0 ~ 10dB
Efficiency 80%
Input Impedance 15K OHMS
Output Impedance 1 OHM
Protection system Short-Circuit to Output, Short on output compared to GND, low impedance at output, High/Low supply
voltage and thermal protection
Min. Supply Voltage 9 VDC
Maximum Power Supply Voltage 16 VDC
Consumption at rest 4 A
Maximum music consumption 595 A
Maximum consumption in sinusoidal signal 1190 A
Dimensions (H x W x D) mm 8.98" x 2.76" x 21.65"
Weight 17.50lb
