Finely Milled Pulp and Egyptian Papyrus Fiber cone material is stiff yet lightweight
Low Damping Rubber speaker surround maintains linear movement better than any other material
Copper Shorting Sleeve placed in the air gap between the pole piece and the voice coil former reduces inductance
Shorting Sleeve improves power delivery to the voice coil, decreases inductive distortion and improves cone linearity
Low Turbulence Cast Aluminum Basket improves airflow to reduce compression of the motor structure
Relatively soft spider to reduce unwanted mechanical stiffness
Speaker housing designed to improve cone control and reduce back-wave interference
3-dimensional cast design dramatically increases the strength and rigidity of the basket
Designed to perform optimally in a real car environment
4 ohms impedance
Frequency response: 45-3,500 Hz
Top-mount depth: 2-15/16"
Sensitivity: 90dB

29mm X-Series Car Tweeters
Silk Dome tweeter construction offers crisply detailed highs with warm characteristic
Dimpled tweeter dome improves the dispersion pattern for improved response
4 ohms impedance
High-temperature voice coil
Robust Tweeter Chamber helps lower the resonant frequency, greatly improving imaging
Ring Radiator design prevents the surround from decoupling at higher frequencies
Improved clarity and fidelity at higher notes reduced strain on the surround
Surface and Flush Mountable
Sensitivity: 94dB
Top-mount depth: 1"
Frequency response: 800-22,000 Hz
