Features

X-treme mid range performance is what PRV Audio’s 10MR1000X is all about. The PRV Audio 10MR1000X is the evolution of our line, after intense 2 years of development we have created the mid range loudspeaker that offers outstanding durability. This specially designed loudspeaker is assembled with top of the line components for long lasting play, even during intense use.

Highlights

3″ Inside/Out aluminum voice coil wound on fiberglass former for hi-temp performance, 8 ohms
1,000 watts continuous program power rating makes high acoustical output
Excellent performance in compact enclosures
100 dB sensitivity, which makes it capable of generating a lot of output!
Detailed vocal reproduction, high fidelity response

10MR1000X-Website-Highlight---Cone-Fibers

A coated woven surround offers smooth, precise geometry during hard play. The light weight cone provides excellent linear response up to 3 kHz, making the 10MR1000X a great solution for high quality two or three-way systems.

10MR1000X-Website-Highlight---Spider-and-Connectors

Extreme car audio enthusiasts will find PRV Audio’s 10MR1000X to be the perfect 10″ mid range door speaker, capable of handling up to 500 watts RMS power (with a suggested 140 Hz, 18 dB/octave high pass filter in place)! The large magnet assembly is attached to a sturdy, reinforced cast-aluminum frame.

High power handling at sensitivity rating of 100 dB 1W/1M which makes it capable of generating a lot of output!

The 3″ inside/outside copper voice coil is wrapped on a glass fiber former for heat resistance and high efficiency, while providing smooth and accurate response. Not only can it handle the force of 500 watts RMS, it does so while remaining linear from 300 to 3,000 Hz.

Technical Details

GENERAL SPECIFICATIONS

Nominal Diameter	10″ (254 mm)
Nominal impedance	8 Ohms
Rated AES Power Handling (RMS)	500 Watts
Program Power	1000 Watts
Sensitivity 2.83V at 1m	100 dB
Recommended Hi Pass Crossover For Full Power Handling	150 Hz 12db Per Octave Crossover
Frequency Response at -10dB	75 – 6,500 Hz
Voice Coil Diameter	3″ (76 mm)
Voice Coil Wire	Copper
Voice Coil Winding Depth	9.0 mm
Former Material	Glass Fiber
Magnetic Gap Depth	8.0 mm
Frame Material	Die Cast Aluminum

THIELE-SMALL PARAMETERS

Equivalent Volume	Vas	28.68 l
Excursion (mathematical)***	Xmax	2.50 mm
Free Air Resonance	Fs	72.02 Hz
Mechanical Factor	Qms	11.22
Electrical Factor	Qes	0.23
Total Factor	Qts	0.22
Cone Area	Sd	391 cm²
Mechanical Mass	Mms	36.26 g
Bl Factor	Bl	19.42 Tm
Dc Resistance	Re	5.2 Ohms
Inductance	Le	0.43 mH at 1 kHz
Mechanical Mass Without Air	Mmd	31.89 g
Mechanical Compliance	Cms	0.134 mm/N

***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4

EXTRA INFO

Overall Diameter	10.23” (260 mm)
Front Mount Baffle Cutout	9.01” (229 mm)
Mounting Depth	4.27” (108.5 mm)
Overall Depth	4.84” (123 mm)
Net Weight	15.43 Lbs (7.0 kg)
Shipping Weight	16.53 Lbs (7.5 kg)
Carton Dimensions W x L x H	11.22” x 11.22” x 6.89” (285 x 285 x 175 mm)
