Build Time 7-14 days
Subwoofer Description
The Lv6m6 Elite is DC Audio’s 4” Coil Beast. It has evolved into what most big builds are after, a sub that can take lots of power and Crush Out the Lows!!
With a world that has access to amplifiers of today's size we knew we needed a subwoofer that could keep up. A Large flat wound 4” Coil and 10” Spaced Spiders with Plenty of Xmax clearance is what we have to offer in the Level 6!!
The new Lv6m6 Elite will find itself at home in the SPL lanes or slappin down your hometowns cruise strip.
To really step it up with this driver take a look at the Carbon Fiber cone and dustcap options available for it.
2025’s New features include a wire cut top plate, Full inner Aluminum sleeve shortning ring, Longer pole and more rearward coil clearance. We have also tooled a new Motor boot with a embossed DC Audio and LV6 Logo on it.
Key Features
-
Extremely strong kraft pulp fiber reinforced cone
-
Wide Long Throw foam surround
-
Dome propylene dust cover with White DC logo
-
10” OD Spaced Spiders
-
Extra heavy duty sewn tinsel lead wire
-
Cast DC Series aluminum black frame / no invert mount
-
FEA analyzed and optimized motor assembly – Fully CNC machined
-
Rubber mounting gasket
-
8 AWG OFC Direct leads
-
4.0” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum former
-
Rubber magnet cover
-
Aluminim shortening ring
-
Extended Pole
T/S Parameters
| M6 Level 6 Subwoofer | 15" | 18" |
|---|---|---|
| Mounting Depth | 12.5" | 13.5" |
| Mounting Hole Diameter | 14.25" | 16.9" |
| Outside Driver Diameter | 15.7" | 18.5" |
| VC Diameter | 4" | 4" |
| Displacement | .24 ft³ | .27 ft³ |
| Power Handling RMS | 4500 watts |
4500 watts |
| Power Handling PEAK | 8000 watts |
8000 watts |
| Ohm Options | d.7/d1/d2 | d.7/d1/d2 |
| Sd | 791 cm² | 1159 cm² |
| Vas | 00.0 L | 00.0 L |
| Cms | 0.00 Mm/n | 0.00 Mm/n |
| Mms | 000.0 g | 000.0 g |
| Fs | 00.0 Hz | 00.0 Hz |
| Bl | 00.0 N/A | 00.0 N/A |
| Re | 0.0 Ohm | 0.0 Ohm |
| Le | 0.0 mH | 0.0 mH |
| Qms | 0.00 | 0.00 |
| Qes | 0.00 | 0.00 |
| Qts | 0.00 | 0.00 |
| Xmax | 34mm | 34mm |
| Ref SPL @1 watt | 00.0db | 00.0 db |
| Suggest Sealed Box | N/A ft³ | N/A ft³ |
| Suggested Ported Box | 3.5 ft³ | 6.0 ft³ |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
Description
Build Time 7-14 days
Subwoofer Description
The Lv6m6 Elite is DC Audio’s 4” Coil Beast. It has evolved into what most big builds are after, a sub that can take lots of power and Crush Out the Lows!!
With a world that has access to amplifiers of today's size we knew we needed a subwoofer that could keep up. A Large flat wound 4” Coil and 10” Spaced Spiders with Plenty of Xmax clearance is what we have to offer in the Level 6!!
The new Lv6m6 Elite will find itself at home in the SPL lanes or slappin down your hometowns cruise strip.
To really step it up with this driver take a look at the Carbon Fiber cone and dustcap options available for it.
2025’s New features include a wire cut top plate, Full inner Aluminum sleeve shortning ring, Longer pole and more rearward coil clearance. We have also tooled a new Motor boot with a embossed DC Audio and LV6 Logo on it.
Key Features
-
Extremely strong kraft pulp fiber reinforced cone
-
Wide Long Throw foam surround
-
Dome propylene dust cover with White DC logo
-
10” OD Spaced Spiders
-
Extra heavy duty sewn tinsel lead wire
-
Cast DC Series aluminum black frame / no invert mount
-
FEA analyzed and optimized motor assembly – Fully CNC machined
-
Rubber mounting gasket
-
8 AWG OFC Direct leads
-
4.0” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum former
-
Rubber magnet cover
-
Aluminim shortening ring
-
Extended Pole
T/S Parameters
| M6 Level 6 Subwoofer | 15" | 18" |
|---|---|---|
| Mounting Depth | 12.5" | 13.5" |
| Mounting Hole Diameter | 14.25" | 16.9" |
| Outside Driver Diameter | 15.7" | 18.5" |
| VC Diameter | 4" | 4" |
| Displacement | .24 ft³ | .27 ft³ |
| Power Handling RMS | 4500 watts |
4500 watts |
| Power Handling PEAK | 8000 watts |
8000 watts |
| Ohm Options | d.7/d1/d2 | d.7/d1/d2 |
| Sd | 791 cm² | 1159 cm² |
| Vas | 00.0 L | 00.0 L |
| Cms | 0.00 Mm/n | 0.00 Mm/n |
| Mms | 000.0 g | 000.0 g |
| Fs | 00.0 Hz | 00.0 Hz |
| Bl | 00.0 N/A | 00.0 N/A |
| Re | 0.0 Ohm | 0.0 Ohm |
| Le | 0.0 mH | 0.0 mH |
| Qms | 0.00 | 0.00 |
| Qes | 0.00 | 0.00 |
| Qts | 0.00 | 0.00 |
| Xmax | 34mm | 34mm |
| Ref SPL @1 watt | 00.0db | 00.0 db |
| Suggest Sealed Box | N/A ft³ | N/A ft³ |
| Suggested Ported Box | 3.5 ft³ | 6.0 ft³ |
Shipping
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
