DS18 PRO 5.25" Neodymium Full-Range Loudspeaker 400 Watts 4-Ohm

Product type: Midrange/Midbass Speakers

Vendor: DS18



Add to the wishlist

DS18 amassed a wealth of experience in manufacturing the most elegant neodymium midranges for those seeking simple perfection. Neodymium magnets provide a higher magnetic flux density in the air gap, which generates a much greater action force in the voice coil. For this reason, Neo magnets have the strongest permanent magnets of all the commercially available speakers. Ranging in sizes, mounting depths, and frequency responses, we have more than 10 different models of Neo midranges to accommodate any build.

Download Manual

Type: Full Range Loudspeaker with Bullet
Size: 5.25"
RMS Power: 200W
MAX Power: 400W
Frequency Response: 242Hz - 13.6KHz
Impedance: 4 Ohm
Sensitivity:  94.6dB
Surround: Cloth Edge
Frame: Aluminum
Cone: Non-Pressed Paper Cone
Magnet: Neodymium
Voice Coil Wire: KCCAW 2 Layer
Voice Coil Size: 1.2"
Magnet Size: NEO
Mounting Depth: 1.74" (44mm)
Cut-Out Dimension: 4.65" (118mm)
