The brand new ALTO Series 10″ Mid Range Loudspeaker.
Highlights:
- Nominal Impedance: 8 Ohms
- Rated AES Power Handling (RMS): 325 Watts
- Program Power: 650 Watts
- Voice Coil Diameter: 2.5″
Great reasons to buy from us:
-
Quality Assurance
Quality Assurance -
Expert Guidance -
Customers Over Profits
Technical Details
GENERAL SPECIFICATIONS
| Nominal Diameter | 10″ (254 mm) |
| Nominal impedance | 8 Ohms |
| Rated AES Power Handling (RMS) |
325 Watts |
| Program Power | 650 Watts |
| Sensitivity 2.83V at 1m | 97.5 dB |
|
Recommended Hi Pass Crossover** **For Full Power Handling |
150 Hz** **12db Per Octave Crossover |
| Frequency Response at -10DB | 80 – 6,500 Hz |
| Voice Coil Diameter | 2.5″ (68 mm) |
| Voice Coil Wire | CCAW |
| Voice Coil Winding Depth | 16.2 mm |
| Former Material | Polyimide |
| Magnetic Gap Depth | 9.5 mm |
| Frame Material | Stamped Steel |
THIELE-SMALL PARAMETERS
| Equivalent Volume | Vas | 41.9 l |
| Excursion (mathematical)*** | Xmax | 5.72 mm |
| Free Air Resonance | Fs | 64.7 Hz |
| Mechanical Factor | Qms | 14.19 |
| Electrical Factor | Qes | 0.48 |
| Total Factor | Qts | 0.47 |
| Cone Area | Sd | 398 cm² |
| Mechanical Mass | Mms | 31.86 g |
| Bl Factor | Bl | 12.25 Tm |
| Dc Resistance | Re | 5.6 Ohms |
| Inductance | Le | 0.44 mH at 1 kHz |
| Mechanical Mass Without Air | Mmd | 27.37 g |
| Mechanical Compliance | Cms | 0.190 mm/N |
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4
EXTRA INFO
| Overall Diameter | 10.10”(256.5 mm) |
| Front Mount Baffle Cutout | 9.20” (233.5 mm) |
| Mounting Depth | 3.90”(99 mm) |
| Overall Depth | 4.23”(107.5 mm) |
| Net Weight | 10.4 Lbs (4.7 kg) |
| Shipping Weight | 12.8 Lbs (5.8 kg) |
| Carton Dimensions W x L x H | 12.9”x 12.9” x 6.9” (328 x 328 x 175mm) |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
