PRV Audio 6FR200 6.5" Full Range Speaker

  • $40.91
    Unit price per
  • Save $9.08
Shipping calculated at checkout.

Apply For Financing

DESCRIPTION

Features

The PRV Audio FR Series sets a new standard of value in high-performance Full Range drivers. The 6FR200 full-range driver is an excellent choice when space is at an absolute minimum, eliminating the need for a tweeter.

This loudspeaker has a dual cone design, the primary cone handles low to midrange frequencies while the smaller secondary cone increases high-frequency response from 80 Hz to 20,000 Hz.
The combination of a low-distortion motor system with a copper ring and a unique woven-cloth dust cap provides exceptional clarity, detail, and dynamics at an impressive 92.5 dB of sensitivity.




Highlights

  • Nominal Impedance: 8 Ohms
  • Rated AES Power Handling (RMS): 100 Watts
  • Program Power: 200 Watts
  • Sensitivity (1W/1m): 92.5 dB
  • Voice Coil Diameter: 1.5″

Technical Details

GENERAL SPECIFICATIONS

Nominal Diameter 6″ (152 mm)
Nominal impedance 8 Ohms
Rated AES Power Handling (RMS) 100 Watts
Program Power 200 Watts
Sensitivity 2.00V at 1m 92.5 dB
Recommended Hi Pass Crossover** **For Full Power Handling 85 Hz** **12db Per Octave Crossover
Frequency Response at -10dB 80 – 20,000 Hz
Voice Coil Diameter 1.5″ (38 mm)
Voice Coil Wire CCAW
Voice Coil Winding Depth 10.0 mm
Former Material Kapton
Magnetic Gap Depth 6.0 mm
Frame Material Stamped Steel
