PRV Audio 6FR200 6.5" Full Range Speaker
- Product Overview
The PRV Audio FR Series sets a new standard of value in high-performance Full Range drivers. The 6FR200 full-range driver is an excellent choice when space is at an absolute minimum, eliminating the need for a tweeter.
This loudspeaker has a dual cone design, the primary cone handles low to midrange frequencies while the smaller secondary cone increases high-frequency response from 80 Hz to 20,000 Hz.
The combination of a low-distortion motor system with a copper ring and a unique woven-cloth dust cap provides exceptional clarity, detail, and dynamics at an impressive 92.5 dB of sensitivity.
- Nominal Impedance: 8 Ohms
- Rated AES Power Handling (RMS): 100 Watts
- Program Power: 200 Watts
- Sensitivity (1W/1m): 92.5 dB
- Voice Coil Diameter: 1.5″
|Nominal Diameter||6″ (152 mm)|
|Nominal impedance||8 Ohms|
|Rated AES Power Handling (RMS)||100 Watts|
|Program Power||200 Watts|
|Sensitivity 2.00V at 1m||92.5 dB|
|Recommended Hi Pass Crossover** **For Full Power Handling||85 Hz** **12db Per Octave Crossover|
|Frequency Response at -10dB||80 – 20,000 Hz|
|Voice Coil Diameter||1.5″ (38 mm)|
|Voice Coil Wire||CCAW|
|Voice Coil Winding Depth||10.0 mm|
|Magnetic Gap Depth||6.0 mm|
|Frame Material||Stamped Steel|
