BRAND NEW TO THE 2024 LINEUP, LOADED AND POWERED
Welcome to the 2024 Soundqubed lineup; Loaded and powered, wedge firing enclosure! This setup provides a simple and easy setup for your truck, your car, your boat. Whatever is in need of a little more bass that has almost no space to use!
This listing is for our HDS2-112SL-WA wedge setup. What does all that mean? This means you are getting a single 12", slim subwoofer, in a stylish, yet functional wedge enclosure that ALREADY HAS AN AMPLIFIER installed, giving the 12" subwoofer the power it needs.
When we say compact design, we mean it. This unit is all of (Bottom) 7.4" Wide X (Top) 4.92" x 19.3" Wide X 15" Height. Again, this includes subwoofer AND amplifier! It would have been easy to just leave the box in black carpet. But then, how would they know what brand is giving the power when you can't see anything? So, we added a fully threaded logo in the biggest design we could fiit, on the back plate of the box. Fold the seat down or up and you'll easily see, what brand is giving you the beats that you're looking for.
Now lets jump into the specifications of this setup.
| MODEL | HDS2-112SL-WA |
| Speaker Size | 12" |
| Impedance | 2ohm |
| Total RMS Power | 300watts |
| Total Max Power | 600watts |
| Sensitivity (1w/1m) | 88dB |
| Frequency Response | 30-250Hz |
| Recommended Lo-pass Crossover | 80Hz |
| Enclosure Material | MDF Wood |
| Amplifier Built in | YES |
| Speaker Specification | |
| Voice Coil Diameter | 1.75" |
| Former Material | Aluminum |
| Winding Material | Copper |
| Cone Material | PPI |
| Dust Cap Material | PPI |
| Surround Material | Rubber |
| Magnet Weight | 50oz |
| Amplifier Specification | |
| Amplifier Type | Monoblock |
| Number of Channels | 1 Channel |
| Signal to noise ratio | 80dB |
| Efficiency at 4ohm | 75% |
| Low level input range | 200mV-6V |
| X-over Range | 50-200Hz |
| Power terminal input size | 8 Gauge |
| Fuse Size | 30amp |
| Remote Level Control | YES |
| Thermal Protection | 167* F |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
Description
BRAND NEW TO THE 2024 LINEUP, LOADED AND POWERED
Welcome to the 2024 Soundqubed lineup; Loaded and powered, wedge firing enclosure! This setup provides a simple and easy setup for your truck, your car, your boat. Whatever is in need of a little more bass that has almost no space to use!
This listing is for our HDS2-112SL-WA wedge setup. What does all that mean? This means you are getting a single 12", slim subwoofer, in a stylish, yet functional wedge enclosure that ALREADY HAS AN AMPLIFIER installed, giving the 12" subwoofer the power it needs.
When we say compact design, we mean it. This unit is all of (Bottom) 7.4" Wide X (Top) 4.92" x 19.3" Wide X 15" Height. Again, this includes subwoofer AND amplifier! It would have been easy to just leave the box in black carpet. But then, how would they know what brand is giving the power when you can't see anything? So, we added a fully threaded logo in the biggest design we could fiit, on the back plate of the box. Fold the seat down or up and you'll easily see, what brand is giving you the beats that you're looking for.
Now lets jump into the specifications of this setup.
| MODEL | HDS2-112SL-WA |
| Speaker Size | 12" |
| Impedance | 2ohm |
| Total RMS Power | 300watts |
| Total Max Power | 600watts |
| Sensitivity (1w/1m) | 88dB |
| Frequency Response | 30-250Hz |
| Recommended Lo-pass Crossover | 80Hz |
| Enclosure Material | MDF Wood |
| Amplifier Built in | YES |
| Speaker Specification | |
| Voice Coil Diameter | 1.75" |
| Former Material | Aluminum |
| Winding Material | Copper |
| Cone Material | PPI |
| Dust Cap Material | PPI |
| Surround Material | Rubber |
| Magnet Weight | 50oz |
| Amplifier Specification | |
| Amplifier Type | Monoblock |
| Number of Channels | 1 Channel |
| Signal to noise ratio | 80dB |
| Efficiency at 4ohm | 75% |
| Low level input range | 200mV-6V |
| X-over Range | 50-200Hz |
| Power terminal input size | 8 Gauge |
| Fuse Size | 30amp |
| Remote Level Control | YES |
| Thermal Protection | 167* F |
Shipping
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
