TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 1200 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 1.200W |
| RMS Power at 1 Ohm 12.6V | 1.250W |
| RMS Power at 2 Ohm 12.6V | 750W |
| RMS Power at 1 Ohm 14.4V | 1.600W |
| RMS Power at 2 Ohm 14.4V | 1.050W |
| Supply Voltage | 9V ~15V DC |
| Frequency Response | 10Hz ~ 15KHz |
| Crossover Low Pass | 90Hz ~ 15KHz |
| Crossover High Pass | 10Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 10K Ohms |
| Impedance Output | 1 OHM |
| Consumption with Signal Musical | 63,5A |
| Consumption with Signal Bass | 127A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 147 mm |
| Weight Kg | 1,75 Kg |
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 1200 – 2 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 1.200W |
| RMS Power at 1 Ohm 12.6V | 1.240W |
| RMS Power at 2 Ohm 12.6V | 700W |
| RMS Power at 1 Ohm 14.4V | 1.600W |
| RMS Power at 2 Ohm 14.4V | 900W |
| Supply Voltage | 9V ~15V DC |
| Frequency Response | 10Hz ~ 15KHz |
| Crossover Low Pass | 90Hz ~ 15KHz |
| Crossover High Pass | 10Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 12K Ohms |
| Impedance Output | 2 OHMS |
| Consumption with Signal Musical | 60A |
| Consumption with Signal Bass | 120A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 147 mm |
| Weight Kg | 1,65 Kg |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
Have questions before you order?
If you need help confirming fitment, power needs, or the right supporting gear for your build,
contact Droppin HZ and we’ll help point you in the right direction.
Description
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 1200 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 1.200W |
| RMS Power at 1 Ohm 12.6V | 1.250W |
| RMS Power at 2 Ohm 12.6V | 750W |
| RMS Power at 1 Ohm 14.4V | 1.600W |
| RMS Power at 2 Ohm 14.4V | 1.050W |
| Supply Voltage | 9V ~15V DC |
| Frequency Response | 10Hz ~ 15KHz |
| Crossover Low Pass | 90Hz ~ 15KHz |
| Crossover High Pass | 10Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 10K Ohms |
| Impedance Output | 1 OHM |
| Consumption with Signal Musical | 63,5A |
| Consumption with Signal Bass | 127A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 147 mm |
| Weight Kg | 1,75 Kg |
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 1200 – 2 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 1.200W |
| RMS Power at 1 Ohm 12.6V | 1.240W |
| RMS Power at 2 Ohm 12.6V | 700W |
| RMS Power at 1 Ohm 14.4V | 1.600W |
| RMS Power at 2 Ohm 14.4V | 900W |
| Supply Voltage | 9V ~15V DC |
| Frequency Response | 10Hz ~ 15KHz |
| Crossover Low Pass | 90Hz ~ 15KHz |
| Crossover High Pass | 10Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 12K Ohms |
| Impedance Output | 2 OHMS |
| Consumption with Signal Musical | 60A |
| Consumption with Signal Bass | 120A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 147 mm |
| Weight Kg | 1,65 Kg |
Shipping
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
REVIEW
Have questions before you order?
If you need help confirming fitment, power needs, or the right supporting gear for your build,
contact Droppin HZ and we’ll help point you in the right direction.
Amplifier build support
Plan the power behind your amplifier.
Amplifiers need the right subwoofer or speaker load, power wire, fusing, ground, and electrical support. Confirm the full system before ordering high-output gear.
