The DIGITAL BASS range was developed for car stereo lovers looking for maximum performance at low frequencies. Its frequency response of 5Hz to 250Hz offers quality and definition in the lower frequencies, delivering powerful and intense bass.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | DB800 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 500W RMS |
| RMS Power at 1 Ohm 12.6V | 665W RMS |
| RMS Power at 2 Ohm 12.6V | 420W RMS |
| RMS Power at 1 Ohm 13.8V | 835W RMS |
| RMS Power at 2 Ohm 13.8V | 500W RMS |
| RMS Power at 1 Ohm 14.4V | 900W RMS |
| RMS Power at 2 Ohm 14.4V | 555W RMS |
| Supply Voltage | 9V ~ 15.5V DC |
| Frequency Response | 5Hz ~ 250Hz |
| Crossover Low Pass | 35Hz ~ 250Hz |
| Crossover High Pass | 5Hz ~ 35Hz (Subsonic) |
| Signal to Noise | >90dB |
| Input Sensitivity | RCA: 200mV ~ 4.5V / HIGH INPUT: 1.5V |
| Input Impedance | RCA: 18K Ohms / HIGH INPUT: 1K Ohms |
| Impedance Output | 1 Ohm |
| Consumption with Signal Musical | 34A |
| Consumption with Signal Bass | 68A |
| Dimensions (H x W x D) mm | 55 x 162 x 158,5 mm |
| Weight Kg | 1 Kg |
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | DB800 – 2 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 500W RMS |
| RMS Power at 2 Ohm 12.6V | 715W RMS |
| RMS Power at 4 Ohm 12.6V | 435W RMS |
| RMS Power at 2 Ohm 13.8V | 855W RMS |
| RMS Power at 4 Ohm 13.8V | 525W RMS |
| RMS Power at 2 Ohm 14.4V | 930W RMS |
| RMS Power at 4 Ohm 14.4V | 570W RMS |
| Supply Voltage | 9V ~15.5V DC |
| Frequency Response | 5Hz ~ 250Hz |
| Crossover Low Pass | 35Hz ~ 250Hz |
| Crossover High Pass | 5Hz ~ 35Hz (Subsonic) |
| Signal to Noise | >90dB |
| Input Sensitivity | RCA: 200mV ~ 4.5V / HIGH INPUT: 1.5V |
| Input Impedance | RCA: 18K Ohms / HIGH INPUT: 1K Ohms |
| Impedance Output | 2 Ohms |
| Consumption with Signal Musical | 34A |
| Consumption with Signal Bass | 68A |
| Dimensions (H x W x D) mm | 55 x 162 x 158,5 mm |
| Weight Kg | 1 Kg |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
Description
The DIGITAL BASS range was developed for car stereo lovers looking for maximum performance at low frequencies. Its frequency response of 5Hz to 250Hz offers quality and definition in the lower frequencies, delivering powerful and intense bass.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | DB800 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 500W RMS |
| RMS Power at 1 Ohm 12.6V | 665W RMS |
| RMS Power at 2 Ohm 12.6V | 420W RMS |
| RMS Power at 1 Ohm 13.8V | 835W RMS |
| RMS Power at 2 Ohm 13.8V | 500W RMS |
| RMS Power at 1 Ohm 14.4V | 900W RMS |
| RMS Power at 2 Ohm 14.4V | 555W RMS |
| Supply Voltage | 9V ~ 15.5V DC |
| Frequency Response | 5Hz ~ 250Hz |
| Crossover Low Pass | 35Hz ~ 250Hz |
| Crossover High Pass | 5Hz ~ 35Hz (Subsonic) |
| Signal to Noise | >90dB |
| Input Sensitivity | RCA: 200mV ~ 4.5V / HIGH INPUT: 1.5V |
| Input Impedance | RCA: 18K Ohms / HIGH INPUT: 1K Ohms |
| Impedance Output | 1 Ohm |
| Consumption with Signal Musical | 34A |
| Consumption with Signal Bass | 68A |
| Dimensions (H x W x D) mm | 55 x 162 x 158,5 mm |
| Weight Kg | 1 Kg |
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | DB800 – 2 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 500W RMS |
| RMS Power at 2 Ohm 12.6V | 715W RMS |
| RMS Power at 4 Ohm 12.6V | 435W RMS |
| RMS Power at 2 Ohm 13.8V | 855W RMS |
| RMS Power at 4 Ohm 13.8V | 525W RMS |
| RMS Power at 2 Ohm 14.4V | 930W RMS |
| RMS Power at 4 Ohm 14.4V | 570W RMS |
| Supply Voltage | 9V ~15.5V DC |
| Frequency Response | 5Hz ~ 250Hz |
| Crossover Low Pass | 35Hz ~ 250Hz |
| Crossover High Pass | 5Hz ~ 35Hz (Subsonic) |
| Signal to Noise | >90dB |
| Input Sensitivity | RCA: 200mV ~ 4.5V / HIGH INPUT: 1.5V |
| Input Impedance | RCA: 18K Ohms / HIGH INPUT: 1K Ohms |
| Impedance Output | 2 Ohms |
| Consumption with Signal Musical | 34A |
| Consumption with Signal Bass | 68A |
| Dimensions (H x W x D) mm | 55 x 162 x 158,5 mm |
| Weight Kg | 1 Kg |
Shipping
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
REVIEW
Plan the power behind your amplifier.
Amplifiers need the right subwoofer or speaker load, power wire, fusing, ground, and electrical support. Confirm the full system before ordering high-output gear.
