| CHARACTERISTICS | DB500.1 – 2 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 500W RMS |
| RMS Power at 2 Ohm 12.6V | 430W RMS |
| RMS Power at 4 Ohm 12.6V | 260W RMS |
| RMS Power at 2 Ohm 13.8V | 515W RMS |
| RMS Power at 4 Ohm 13.8V | 310W RMS |
| RMS Power at 2 Ohm 14.4V | 560W RMS |
| RMS Power at 4 Ohm 14.4V | 340W RMS |
| Supply Voltage | 9V ~15.5V DC |
| Frequency Response | 5Hz ~250Hz |
| Crossover Low Pass | 35Hz ~250Hz |
| Crossover High Pass | 5Hz ~35Hz (Subsonic) |
| Signal to Noise | >90dB |
| Input Sensitivity | RCA: 200mV / HIGH INPUT: 1.5V |
| Input Impedance | RCA: 14K Ohms / HIGH INPUT: 1K Ohms |
| Impedance Output | 2 OHMS |
| Consumption with Signal Musical | 21,5A |
| Consumption with Signal Bass | 43A |
| Dimensions (H x W x D) mm | 55 x 162 x 125.5 mm |
| Weight Kg | 0.75 Kg |
| CHARACTERISTICS | DB500.1 – 4 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 500W |
| RMS Power at 4 Ohm 12.6V | 420W |
| RMS Power at 8 Ohm 12,6V | 240W |
| RMS Power at 4 Ohm 13.8V | 500W |
| RMS Power at 8 Ohm 13,8V | 290W |
| RMS Power at 4 Ohm 14.4V | 550W |
| RMS Power at 8 Ohm 14,4V | 320W |
| Supply Voltage | 9V ~15.5V DC |
| Frequency Response | 5Hz ~250Hz |
| Crossover Low Pass | 35Hz ~250Hz |
| Crossover High Pass | 5Hz ~35Hz (Subsonic) |
| Signal to Noise | >90dB |
| Input Sensitivity | RCA: 200mV / HIGH INPUT: 1.5V |
| Input Impedance | RCA: 15K Ohms / HIGH INPUT: 1K Ohms |
| Impedance Output | 4 OHMS |
| Consumption with Signal Musical | 20A |
| Consumption with Signal Bass | 40A |
| Dimensions (H x W x D) mm | 55 x 162 x 125.5 mm |
| Weight Kg | 0.75 Kg |
