TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | HL2000.4 – 2 OHMS |
|---|---|
| Number of Channels | 4 |
| RMS Power at 2 Ohm 12.6V | 4 x 500W RMS (STEREO) |
| RMS Power at 4 Ohm 12.6V | 4 x 290W RMS (STEREO) |
| RMS Power at 2 Ohm 13.8V | 4 x 580W RMS (STEREO) |
| RMS Power at 4 Ohm 13.8V | 4 x 364W RMS (STEREO) |
| Power @ 12.6V Bridge 4 Ohms | 2 x 1000W RMS |
| Power @ 13.8V Bridge 4 Ohms | 2 x 1160W RMS |
| Supply Voltage | 9V ~ 15V DC |
| Frequency Response | 19Hz ~ 26KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | >90 dB |
| Harmonic Distortion | >0,3 % THD |
| Input Sensitivity | 200mV |
| Input Impedance | 15K OHMS |
| Impedance Output | STEREO: 2 OHMS / BRIDGE: 4 OHMS |
| Consumption with Signal Musical | 96A |
| Consumption with Signal Bass | 192A |
| Dimensions (H x W x D) mm | 77.5 x 235 x 240.5 mm |
| Weight Kg | 2,7 Kg |
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | HL2000.4 – 1 OHM |
|---|---|
| Number of Channels | 4 |
| RMS Power at 1 Ohm 12.6V | 4 x 435W RMS (STEREO) |
| RMS Power at 2 Ohm 12.6V | 4 x 280W RMS (STEREO) |
| RMS Power at 1 Ohm 14.4V | 4 x 545W RMS |
| RMS Power at 2 Ohm 14.4V | 4 x 365W RMS |
| Power @ 12.6V Bridge 2 Ohms | 2 x 870W RMS |
| Power @ 13.8V Bridge 2 Ohms | 2 x 1100W RMS |
| Supply Voltage | 9V ~15V DC |
| Frequency Response | 20Hz ~26KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | >90dB |
| Harmonic Distortion | >0,3 % THD |
| Input Sensitivity | 200mV |
| Input Impedance | 15K Ohms |
| Impedance Output | STEREO: 1 OHM / BRIDGE: 2 OHMS |
| Consumption with Signal Musical | 97A |
| Consumption with Signal Bass | 194A |
| Dimensions (H x W x D) mm | 77.5 x 235 x 240.5 mm |
| Weight Kg | 2.8 Kg |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
Have questions before you order?
If you need help confirming fitment, power needs, or the right supporting gear for your build,
contact Droppin HZ and we’ll help point you in the right direction.
Description
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | HL2000.4 – 2 OHMS |
|---|---|
| Number of Channels | 4 |
| RMS Power at 2 Ohm 12.6V | 4 x 500W RMS (STEREO) |
| RMS Power at 4 Ohm 12.6V | 4 x 290W RMS (STEREO) |
| RMS Power at 2 Ohm 13.8V | 4 x 580W RMS (STEREO) |
| RMS Power at 4 Ohm 13.8V | 4 x 364W RMS (STEREO) |
| Power @ 12.6V Bridge 4 Ohms | 2 x 1000W RMS |
| Power @ 13.8V Bridge 4 Ohms | 2 x 1160W RMS |
| Supply Voltage | 9V ~ 15V DC |
| Frequency Response | 19Hz ~ 26KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | >90 dB |
| Harmonic Distortion | >0,3 % THD |
| Input Sensitivity | 200mV |
| Input Impedance | 15K OHMS |
| Impedance Output | STEREO: 2 OHMS / BRIDGE: 4 OHMS |
| Consumption with Signal Musical | 96A |
| Consumption with Signal Bass | 192A |
| Dimensions (H x W x D) mm | 77.5 x 235 x 240.5 mm |
| Weight Kg | 2,7 Kg |
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | HL2000.4 – 1 OHM |
|---|---|
| Number of Channels | 4 |
| RMS Power at 1 Ohm 12.6V | 4 x 435W RMS (STEREO) |
| RMS Power at 2 Ohm 12.6V | 4 x 280W RMS (STEREO) |
| RMS Power at 1 Ohm 14.4V | 4 x 545W RMS |
| RMS Power at 2 Ohm 14.4V | 4 x 365W RMS |
| Power @ 12.6V Bridge 2 Ohms | 2 x 870W RMS |
| Power @ 13.8V Bridge 2 Ohms | 2 x 1100W RMS |
| Supply Voltage | 9V ~15V DC |
| Frequency Response | 20Hz ~26KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | >90dB |
| Harmonic Distortion | >0,3 % THD |
| Input Sensitivity | 200mV |
| Input Impedance | 15K Ohms |
| Impedance Output | STEREO: 1 OHM / BRIDGE: 2 OHMS |
| Consumption with Signal Musical | 97A |
| Consumption with Signal Bass | 194A |
| Dimensions (H x W x D) mm | 77.5 x 235 x 240.5 mm |
| Weight Kg | 2.8 Kg |
Shipping
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
REVIEW
Have questions before you order?
If you need help confirming fitment, power needs, or the right supporting gear for your build,
contact Droppin HZ and we’ll help point you in the right direction.
Amplifier build support
Plan the power behind your amplifier.
Amplifiers need the right subwoofer or speaker load, power wire, fusing, ground, and electrical support. Confirm the full system before ordering high-output gear.
