Take Your Audio System to the Next Level
The EZY DSP612+ delivers advanced tuning, high-definition streaming, and seamless integration into any car audio system. Whether you’re upgrading a factory setup or building a custom system, this DSP provides the ultimate combination of control, flexibility, and precision.
Unmatched Flexibility, Standard in Every Unit
High-Level Inputs:
- Designed for factory systems where replacing the radio isn’t an option.
- Effortlessly converts high-level signals into clean digital audio, upgrading your factory system with ease.
- Retain all OEM features while unlocking premium sound quality.
Low-Level RCA Inputs:
- Ideal for custom setups with aftermarket radios.
- Delivers a direct, clean signal path to your amplifiers for maximum clarity and performance.
Bluetooth Streaming with APTX-HD:
- Stream your music in TRUE high-definition directly from your phone or other Bluetooth devices.
- Built-in APTX-HD Bluetooth technology provides studio-quality wireless audio for a seamless listening experience.
- Forget traditional head units—your smartphone becomes the ultimate control hub for your audio system.
Key Features
Every feature is included as standard to provide maximum flexibility and value:
Inputs:
- 6 RCA inputs (high-level or low-level) for seamless integration with any system.
Outputs:
- 12 RCA outputs with 4.2Vrms output voltage for precise audio distribution to amplifiers.
Bluetooth Streaming:
- Built-in Bluetooth 5.0 with APTX-HD for TRUE HD wireless streaming.
Connectivity Options:
- Optical and coaxial inputs for flexible connection to modern audio sources.
Advanced Audio Processing:
- 31-band EQ for precise frequency, Q-value, and gain control.
- High/low-pass filters with adjustable slopes for professional tuning.
- Phase adjustment (0° to 360°).
- Delay control up to 20ms (273 inches) for accurate speaker timing.
Custom Presets:
- Save and instantly recall up to 6 audio profiles for different setups.
Noise Control:
- Features a noise gate, limiter, and minimum source attenuation for crystal-clear audio.
Specifications
| Specification | Value |
|---|---|
| Dynamic Range | ≥100dB |
| Signal-to-Noise Ratio | ≥102dB |
| Total Harmonic Distortion | ≤0.05% |
| Frequency Response | 20Hz ~ 20kHz |
| Sampling Rate | 48kHz/24Bit |
| RCA Input Voltage (RMS) | 2.8Vrms |
| RCA Output Voltage (RMS) | 4.2Vrms |
| RCA Input Impedance | 10kΩ |
| RCA Output Impedance | 51Ω |
| Max Input/Output Signal | 12Vpp |
| Working Voltage | DC 9V ~ 16V |
| Operating Temperature | -30°C to 70°C (-22°F to 158°F) |
| Dimensions | 6 in x 5 in x 3 in |
| Weight | 2 lbs |
Why Choose the EZY DSP612+?
- Ultimate Flexibility: High-level and low-level inputs make it compatible with both factory and aftermarket systems.
- True HD Bluetooth Audio: Stream directly from your phone with APTX-HD Bluetooth 5.0 for studio-level sound quality.
- Crystal-Clear Audio: Dynamic range of ≥100dB and distortion ≤0.05% ensures every detail of your music is heard.
- Comprehensive Tuning Options: Advanced features like a 31-band EQ, phase adjustment, and delay control let you fine-tune your system to perfection.
EZY DSP App Now Available
Take complete control of your sound system with the EZY DSP App, now available on:
Download the app and customize your audio settings directly from your favorite device to achieve the ultimate listening experience.
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
