Pioneer DMH-WC5700NEX Double DIN Mechless Bluetooth In-Dash Car Stereo Receiver with 6.78” Touchscreen Display

  • $749.99
    Unit price per

Shipping calculated at checkout.



• Double DIN In-Dash Bluetooth Mechless Car Stereo Receiver
• 6.8" WVGA Display Display
• 50 watts x 4 channel MAX / 22 watts x 4 channel RMS
• 3 Pairs of 4.0V preamp outputs (front/rear/subwoofer)
• 13-band equalizer


Get to know the Pioneer DMH-WC5700NEX

There are some vehicles that are difficult to fit with a stereo. Pioneer's DMH-WC5700NEX helps resolve that problem all credited to its modular design that offers a "black box" which is separate from the display. Its 6.78" screen works in most double-DIN (4' tall) openings regardless of its depth. This device is a mechless receiver meaning any type of CD can't be played but media can still be enjoyed with or without wires through Bluetooth, Apple CarPlay, Amazon Alexa, Android Auto, Bluetooth, Screen Mirroring and an HD Radio. Additionally, there is a rear USB input, a mini rear aux input and a micro-HDMI input. The 13-band equalizer maximizes audio signal sent to the built-in amplifier. It's iDatalink Maestro (not included) compatible which lets you keep factory extras that you'd otherwise lose when a new radio is installed. This product features an innovative and powerful new user interface that is responsive and highly customizable. It is designed especially for today's smartphone driven lifestyle

Product Details:

  • Double DIN In-Dash Bluetooth Mechless Car Stereo Receiver with Remote
  • 6.8" WVGA Display
  • Built-in Bluetooth for hands-free and audio streaming
  • CEA-2006 compliant amplifier
  • Seperate DIN (2" tall) chassis can be installed together or independently while fitting into difficult vehicles where standard radios won't fit
  • Power Output:
    • Peak: 50 watts x 4 channel
    • RMS: 22 watts x 4 channel
  • Wireless remote control included
  • MP3 ID3 Tag Display (Title/Artist/Album)

Playback and Audio Features:

  • Plays media loaded with MP3, WMA, AAC, and high-res FLAC, WAV, and DSD music files
  • AM/FM tuner with 18FM/6AM presets
  • 13 band Equalizer

Expandability Options:

  • 6-channel preamp outputs (4-volt, front, rear, sub)
  • SiriusXM Satellite Radio Ready: SiriusXM SXV300v1 and subscription required and sold separately
  • Front Auxiliary Input: 3.5mm headphone jack allows connection to your mobile device
  • Front and Rear USB Input: USB port allows connection to digital devices such as flash drives, portable media players, etc.
  • Second camera input for an optional front-view camera
  • Built-in adjustable parking guides to back up safely
  • Dedicated Backup Camera Input: Used for universal rear view cameras with an RCA composite input
  • Steering Wheel Control Ready: Axxess ASWC-1 required and sold separately
  • Rear RCA Video Output: Used for connection to separate monitors and other devices
  • Rear RCA Audio/Video Input: Used for connecting video accessories such as game consoles, video cameras, etc.

Bluetooth Features:

  • Built-in Bluetooth technology for hands-free talking and audio streaming
  • Bluetooth range up to 5 meters
  • Supports SMS message notifications and A2DP audio streaming
  • Bluetooth Profiles Supported:
    • HFP: Hands Free Profile allows a hands-free car kit to connect to a compatible mobile phone
    • HSP: Headset Profile enables a Bluetooth headset to connect to a compatible mobile phone
    • PBAP: Phone Book Access Profile allows the car stereo to display the name of the incoming caller, as well as access the contact list of the mobile phone directly from the car stereo
    • A2DP: Advanced Audio Distribution Profile allows high quality audio to be streamed from an audio device to the car stereo
    • AVRCP: Audio/Video Remote Control Profile supports basic remote control functions (play, pause, etc) via Bluetooth
    • OPP: Object Push Profile for sending basic "objects" such as pictures and other virtual material
    • SYNC: Synchronization Profile enables the synchronization of Personal Information Manager (PIM) items
    • SPP: Serial Port Profile provides a wireless replacement for RS-232 based serial communications
  • Works with most Bluetooth enabled cell phones
  • Includes a built-in microphone for clear, convenient, distortion-free talking***
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

FEATURES & SPECS Key features Key features Apple CarPlay
Wireless Android Auto
Wireless CarPlay
Android Auto
Floating Touchscreen
Built-in navigation
Maestro compatible
SiriusXM ready
USB input
HDMI input
Aux input
In-Dash Receiver Specifications Receiver Size Double DIN Anti-Theft Security None Motorized Faceplate No Remote Control Yes Peak Power Output 50 watts x 4 channel RMS Power Output 22 watts x 4 channel Preamp RCA Outputs 3 Sets (6-channel) Dedicated Subwoofer Preamp RCA Output Yes Preamp Voltage 4 volts Built-In Equalizer 13 band Display Type WVGA Display Display Color Full Color CD Signal-to-Noise 90 dB CEA-2031 Compliant Yes Playback Features AM/FM Tuner Yes FM Presets 18 AM Presets 6 Radio Data System (RDS) Yes CD-R/RW Playback No MP3 Playback Yes WMA Playback Yes Video playback Yes DVD Region Number
Dual Zone
Hi-Res Certified
Video in-motion bypass No
Audio / Video Inputs USB Input Yes Number of Front USB Inputs
Number of Rear USB Inputs 1 Additional Audio/Video Inputs 1 Video RCA Input
1 Set of Rear RCA A/V Inputs
Monitor Screen Features Touchscreen Yes Screen Size 6.8" Monitor Angle Adjustment None Display Adjustment Brightness
MirrorLink Compatible No Device Mirroring Yes
Navigation Features Map Database Determined By Phone Connected Traffic Lane Guidance
Navigation During Audio Playback Yes Navigation During Video Playback No Languages English Map Dimensional Display 2D
Speed Display
Map Source Determined by phone connected Text-to-Speech
Traffic Tuner
Customizable POI
Expandability Features Navigation Determined by phone connected Compatible Smartphones iPhone (iOS)
Audio/Video Outputs HDMI
1 Video RCA Output
Satellite Radio SiriusXM Ready (Accessory sold separately) HD Radio Yes (Built-In/Included HD Radio Tuner) Bluetooth Connectivity Yes (Built-in/Included [Bluetooth Controls, Adapter and/or Microphone Included]) A2DP Music Streaming Yes Steering Wheel Control Compatible Yes (Accessory required and sold separately) Maestro Compatible Yes Rear View Camera Input Yes (Universal) Memory Card Reader No
Smartphone Integration iPhone/iPod Features Apple CarPlay
Apple CarPlay (wireless)
MirrorLink Control
Android Features Android Auto
Android Auto (wireless)
Android Audio Integration Yes (via Bluetooth Connection) Android Video Connection
What is in the box? Product and accessories In-dash receiver Paperwork User manual
Quick start guide
Authorized Dealer Authorized Dealer Authorized Dealer
Warranty and Return Policy Parts Warranty Duration 1 year Labor Warranty Duration 1 year Warranty Provider Manufacturer
