PRV AUDIO 1" EXIT WAVEGUIDE WGP14-25 -S Series
DESCRIPTION
- Product Overview
Product Overview
Add a little color to your sound, in a good way, with PRV Audio’s WGP14-25 blue finished exponential horn. At under 4″ of depth this horn makes installation easy in tight spaces.
A standard 1-3/8″-18 TPI Screw on mount is compatible with most 1″ compression drivers. The WGP14-25 Blue-S is constructed from non-resonant ABS plastic making it perfect for outdoor or automotive use. Acoustic loading is maintained down to 600 Hz.
Highlights
- Under 4″ of mounting depth for installation in tight spaces
- 1″ Exit throat
- Non-resonant reinforced plastic construction
- Minimum recommended frequency of 600 Hz
- UV resistant Chrome Finish
| Throat Diameter | 1” (25.4 mm) |
| Mounting Type | Screw-on |
| Thread dimensions | 1-3/8″ |
| Nominal Coverage | |
| Horizontal | 45° |
| Vertical | 45° |
| Flare type | Exponential |
| Material | Plastic (ABS) |
| Finish / Coating | Blue |
| Dimensions | |
| Height | 6.09″ (154.7 mm) |
| Width | 6.09″ (154.7 mm) |
| Depth | 4.33″ (110 mm) |
| Mount Depth | 3.98″ (100 mm) |
| Baffle Cutout | |
| Width | 5.51″ (140 mm) |
| Net weight | 0.2 lb (0.09 kg) |
