DS18 GEN-XX15.4DHE 15" High Excursion Car Subwoofer 1200 Watts 4-Ohm DVC Double Magnet

  • $174.95
    Unit price per

Shipping calculated at checkout.

SHIPPING & DELIVERY INFORMATION

DESCRIPTION

High excursion is now the mainstream and usually this feature is very expensive and enthusiasts sometimes miss out on amazing bass because of the large cost. We want to bring the experience of low frequency bass to even the entry level user. The GEN-XX15.4DHE is the answer to that issue. This subwoofer is a mid-tier addition that comes in at an amazing price point while getting all those features other much more expensive high excursion subs come with.
Also, with a power rating of 600w RMS and 1200w Max this sub does not require large amounts of power to come alive and beat up the block.

Highlights

  • High Excursion surround for a very high amount of xmax.
  • Great power handling of 600w RMS and 1200w max.
  • Long three voice coil and extended magnet to accommodate the xmax increase.
  • FS of 30 Hz so you can easily dip in the subsonic range with no issues along as your box is tuned correctly.



SPECIFICATIONS
Nominal Diameter 15"
Nominal Impedance 4 + 4 Ohms
RMS Power Handling 600 Watts
MAX Power Handling 1200 Watts
Sensitivity (1w/1m) 87.4 dB
Frequency Response 20Hz - 1KHz
Recommended Lo Pass Crossover 80Hz
MOTOR
Voice Coil Diameter 2"
VC Former Material Black Aluminum
Winding Material SV
Cone Material Paper
Dust Cap Material PPI
Surround Material Foam
Basket Material Steel
Basket Color and Finish Glossy Red
Magnet Material Ferrite
Magnet Weight 136 oz
Displacement Volume 3.26L
THIELE & SMALL PARAMETERS
Equivalent Volume Vas 105.083 L
Excursion (one way) Xmax 25mm
Free Air Resonance Fs 27 Hz
Mechanical Factor Qms 3.658
Electrical Factor Qes 0.583
Total Factor Qts 0.503
Mechanical Mass Mms 309.67g
Mechanical Compliance Cms 0.112mm/N
BL Factor BL 24.045N/A
Voice Coil Inductance Le 0.6741mH
Cone Area Sd 814.332cm2
DC Resistance Re 3.2+3.2 ohms
Efficiency Bandwidth Product EBP 46.3
MEASUREMENTS
Overall Diameter 10.28" / 261 mm
Overall Depth 7.21" / 183 mm
Front Mount Baffle Cutout 9.14" / 232 mm
Mounting Depth 6.15" / 156mm
Motor Diameter 6.15" / 156mm
