The BRAVO FULL line was developed for car audio enthusiasts seeking maximum performance and quality in FULL-RANGE amplifiers.
Its frequency response of 5Hz to 7kHz offers audio quality and definition, allowing it to be used with subwoofers, woofers, drivers, and tweeters.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 12000 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 12.000W |
| RMS Power at 1 Ohm 12.6V | 12.000W |
| RMS Power at 2 Ohm 12.6V | 7.120W |
| RMS Power at 1 Ohm 14.4V | 12.800W |
| RMS Power at 2 Ohm 14.4V | 8.510W |
| Supply Voltage | 9V ~ 16V DC |
| Frequency Response | 5Hz ~ 7KHz @ 1 Ohm |
| Crossover Low Pass | 90Hz ~ 7KHz |
| Crossover High Pass | 5Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 19K Ohms |
| Impedance Output | 1 OHM |
| Consumption with Signal Musical | 590A |
| Consumption with Signal Bass | 1180A |
| Dimensions (H x W x D) mm | 79,7 x 574 x 231,5 mm |
| Weight Kg | 8,6 Kg |
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
Description
The BRAVO FULL line was developed for car audio enthusiasts seeking maximum performance and quality in FULL-RANGE amplifiers.
Its frequency response of 5Hz to 7kHz offers audio quality and definition, allowing it to be used with subwoofers, woofers, drivers, and tweeters.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 12000 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 12.000W |
| RMS Power at 1 Ohm 12.6V | 12.000W |
| RMS Power at 2 Ohm 12.6V | 7.120W |
| RMS Power at 1 Ohm 14.4V | 12.800W |
| RMS Power at 2 Ohm 14.4V | 8.510W |
| Supply Voltage | 9V ~ 16V DC |
| Frequency Response | 5Hz ~ 7KHz @ 1 Ohm |
| Crossover Low Pass | 90Hz ~ 7KHz |
| Crossover High Pass | 5Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 19K Ohms |
| Impedance Output | 1 OHM |
| Consumption with Signal Musical | 590A |
| Consumption with Signal Bass | 1180A |
| Dimensions (H x W x D) mm | 79,7 x 574 x 231,5 mm |
| Weight Kg | 8,6 Kg |
Shipping
| Shipping | Most items ship within 1–3 business days. Delivery time varies by item, vendor, and destination. |
Need help before ordering? Contact Droppin HZ and we can help confirm fitment, power needs, or supporting gear for your build.
REVIEW
Plan the power behind your amplifier.
Amplifiers need the right subwoofer or speaker load, power wire, fusing, ground, and electrical support. Confirm the full system before ordering high-output gear.
