Taramps DS 800x4 800 Watt Class D 4 Channel Amplifier

  • $176.99
    Unit price per

Shipping calculated at checkout.

Apply For Financing


Operation class D
Number of Channels 04
Maximum power @ 12,6 VDC - 2 OHMS: 800W RMS (4 x 200W RMS)
@ 12,6 VDC - 4 OHMS: 544W RMS (4 x 136W RMS)
Input Sensitivity 250mV
Signal to Noise Ratio >88dB
Frequency response 10Hz to 36KHz (-3dB)
Crossover high pass (HPF) 90Hz (-12dB/8ª) Fixed
Crossover low pass (LPF) 90Hz (-12dB/8ª) Fixed
Input Impedance 18K Ohms
Output Impedance 2 Ohms
Protection system Output overload
Min. Supply Voltage 9VDC
Maximum Power Supply Voltage 16VDC
Consumption at rest 1.4A
Maximum music consumption @12.6VDC: 43A
Maximum consumption in sinusoidal signal 86A
Dimensions (H x W x D) mm 7.17" x 2.05" x 8.94"
Weight 3.52lb
