• 6.8" Capacitive Touchscreen Digital Media Receiver • Built-in Bluetooth for hands-free and audio streaming • 50W x 4 Chan. MAX • 14W x 4 Chan. RMS • AM/FM tuner with 18FM/12AM presets • 13-band Customizable Graphic Equalizer • Pioneer App Compatibility • 2006 CEA Compliant • Optional Wireless Remote Control
General Features:
6.8" Capacitive Touchscreen Digital Media Receiver
Built-in Bluetooth for hands-free and audio streaming
CEA-2006 compliant amplifier
Power Output:
Peak: 50 watts x 4 channels
RMS: 14 watts x 4 channels
Wireless remote control included
CD text information display
MP3 ID3 Tag Display (Title/Artist/Album)
Authorized Internet Dealer
1-year Manufacturer's Warranty
Playback and Audio Features:
Playback of CD, CD-R/RW, DVD±R/RW, MP3 and WMA
Playback of (any region/region ##) DVD discs
AM/FM tuner with 18FM/12AM presets
Compatible with Apple iPhone 6/6+ and iOS 8 software
Dynamic Soundstage Organizer
Pioneer App Compatibility: Available for Apple and Android
13-band Customizable Graphic Equalizer
24-bit Digital Analog Converter (DAC) to enhance your MP3/WMA playback
Bluetooth Features:
Built-in Bluetooth technology for hands-free talking and audio streaming
Bluetooth version
Bluetooth range up to 5 meters
Supports SMS message notifications and A2DP audio streaming
Bluetooth Profiles Supported:
HFP: Hands Free Profile allows a hands-free car kit to connect to a compatible mobile phone
HSP: Headset Profile enables a Bluetooth headset to connect to a compatible mobile phone
PBAP: Phone Book Access Profile allows the car stereo to display the name of the incoming caller, as well as access the contact list of the mobile phone directly from the car stereo
A2DP: Advanced Audio Distribution Profile allows high quality audio to be streamed from an audio device to the car stereo
AVRCP: Audio/Video Remote Control Profile supports basic remote control functions (play, pause, etc) via Bluetooth
OPP: Object Push Profile for sending basic "objects" such as pictures and other virtual material
SYNC: Synchronization Profile enables the synchronization of Personal Information Manager (PIM) items
SPP: Serial Port Profile provides a wireless replacement for RS-232 based serial communications
Works with most Bluetooth enabled cell phones
Includes a (external wired/built-in) microphone for clear, convenient, distortion-free talking
Also Found As:
Check out the DMH-340EX Owner's ManualFEATURES & SPECSKey featuresKey featuresBluetooth Touchscreen USB inputIn-Dash Receiver SpecificationsReceiver SizeDouble DINAnti-Theft SecurityNoneMotorized FaceplateNoRemote ControlNoPeak Power Output50 watts x 4 channelRMS Power Output14 watts x 4 channelPreamp RCA Outputs3 Sets (6-channel)Dedicated Subwoofer Preamp RCA OutputYesPreamp Voltage2 voltsBuilt-In Equalizer13 Band EQDisplay TypeCapacitive Touch LCDDisplay ColorFull ColorCD Signal-to-Noise85 dBCEA-2031 CompliantYesPlayback FeaturesAM/FM TunerYesFM Presets18AM Presets12Radio Data System (RDS)YesCD-R/RW PlaybackYesMP3 PlaybackYesWMA PlaybackYesVideo playbackYesDVD Region Number1Dual Zone Hi-Res Certified Video in-motion bypassNoAudio / Video InputsUSB InputYesNumber of Front USB Inputs Number of Rear USB Inputs Monitor Screen FeaturesTouchscreenYesScreen Size6.8"Monitor Angle AdjustmentNoneMirrorLink Compatible Device Mirroring Navigation FeaturesMap DatabaseDetermined By Phone ConnectedNavigation During Audio PlaybackYesNavigation During Video PlaybackNoLanguagesEnglishMap Dimensional Display2D 3DSpeed Display Map Source Text-to-SpeechNoTraffic Tuner Expandability FeaturesNavigation Compatible SmartphonesiPhone (iOS) AndroidSatellite RadioNoHD Radio Bluetooth ConnectivityYes (Integrated front-panel microphone, No External Mic Included)A2DP Music StreamingYesSteering Wheel Control CompatibleYesMaestro CompatibleNoRear View Camera InputYes (Universal)Memory Card ReaderNoSmartphone IntegrationiPhone/iPod FeaturesApp CompatibleAndroid FeaturesApp CompatibleAndroid Audio IntegrationYes (via Bluetooth Connection)Android Video Connection What is in the box?Product and accessoriesIn-dash receiverPaperworkUser manual Warranty/Registration card Quick start guideAuthorized DealerAuthorized DealerAuthorized DealerWarranty and Return PolicyParts Warranty Duration1 yearLabor Warranty Duration1 yearWarranty ProviderManufacturer
