DS18 ELITE 6x9" 2-Way Coaxial Speakers with Kevlar Cone 360 Watts 4-Ohm (Sold as pairs)

  • $114.95
    Unit price per
Snap Logo Lease for as low as $/week Get Approved

Shipping calculated at checkout.

Apply For Financing

DESCRIPTION

The ZXI series is the go to DS18 line for great sounding audio that not only has very high volume, but also amazing sound quality for an amazing price. The ZXI 694 is 6x9 inch, 4 ohm coaxial speaker designed for mid tier audio enthusiasts to the extreme as they have an amazing range of frequencies and loudness. The 2 way design will ensure that you receive a full range of frequencies for an audio experience that you will truly remember.

Highlights

  • The ZXi line is a complete line of amps, subs, mids, and tweeters so you can match all your equipment up to be the same for an amazing show quality look.
  • 6x9" inch 2 way 4 ohm speaker requiring 120w RMS and 360w max power handling that gives amazing sound from low to extremely high volume.
  • 2 way design will be sure to give you a full range of frequencies for an amazing audio experience to remember.
Nominal Diameter 6X9”
Nominal Impedance 4 ohm
RMS Power Handling 120 Watts
MAX Power Handling 360 Watts
Sensitivity (1w/1m) 92dB
Frequency Response 31.5Hz-20KHz
Recommended HI Pass Crossover 50Hz
Speaker Type 2-Way
Midrange:
Voice Coil Diameter 1.2” / 30.4mm
Voice Coil Former Material KSV
Winding Material EISV
Cone Material Glass fiber
Surround Material Rubber
Basket Material Steel
Magnet Material. Barium Ferrite
Magnet Weight 19.4 oz / 550g
Tweeter:
Nominal Diameter 1" (25.4mm)
Voice Coil Diameter 0.8"(ø20.4mm)
Voice Coil Former Material KSV
Winding Material EISVM
Diaphragm Material PEI
Magnet Material Neodymium
Magnet Weight 8.5g
Thiele & Small Parameters
Equivalent Volume 17.52L
Excursion (one way) 3.3mm
Free Air Resonance 58Hz
Mechanical Factor 5.77
Electrical Factor 1.18
Total Factor 0.98
Mechanical Mass 23.44g
Mechanical Compliance 286mm/N
BL Factor 5.18
Cone Area 207.7cm2
DC Resistance 3.5 ohm
Mechanical Mass w/o air 20g
Measurements
Overall Diameter 6.37x9.25” /162x235mm
Overall Depth 3.66” / 93mm
Front Mount Baffle Cutout 5.94x8.70” / 151x221mm
Mouting Depth 3.22” / 82mm
Motor Diameter 4.09” / 104mm
